SMC Fiberglass Water Tank
Features of SMC fiberglass water tank:
SMC fiberglass water tank is a type of water tank used in various industrial and civil buildings for water supply, HVAC, etc. It is characterized by a smooth surface, no cracks, and no bubbles in the welds. SMC fiberglass water tank refers to a water tank processed from fiberglass as raw material. Fiberglass reinforced plastic refers to plastic reinforced with glass fibers and their fabrics, which is lightweight, hard, non-conductive, has high mechanicalstrength, SMC fiberglass water tank is equipped with special sealing strips and bolted connection structure, which is easy to assemble and will not cause water leakage or poor sealing. The box body is beautiful: white appearance color, giving people a more comfortable feeling!
The manufacturing method of SMC fiberglass water tank:
The Smc fiberglass water tank is assembled on-site from SMC molded panels, sealing materials, metal structural components, and piping systems. In recent years, SMC fiberglass water tanks in China have been manufactured using the method of machine pressing, which involves high temperature, compression, and mechanical pressing. The compression molding process and molding material molding are basically the same in terms of compression technology and equipment conditions. The difference is that the molding process uses impregnated tape as the molding material, while the molding material uses sheet, lump, or loose molding materials. First, a certain amount of molding material is placed in a metal mold, and then molded at a certain temperature and pressure to produce the desired fiberglass product.
This production molding method produces products with precise dimensions, smooth surfaces, high efficiency in one-time molding, and stable product quality. Products that require large-scale production, such as fiberglass water tanks, are
more suitable. The skill level and proficiency of the operators directly affect the quality of the SMC fiberglass water tank. A small mistake may result in the scrapping of the entire fiberglass water tank. We at Dafeng regularly train the operators.
In terms of manufacturing technology, the manufacturing method of press forming is chosen. Increased the strength of earthquake resistance and impact resistance, overcame the defect of uneven strength of hand pasted products, and improved the compressive strength and service life; In terms of exterior design, the central part of the plate has a concave curvature, which improves the pressure bearing capacity of the water tank, increases the strength of earthquake resistance and impact resistance, overcomes the defect of uneven strength of hand pasted products, and improves the pressure resistance strength and service life; In terms of exterior design, the central part of the plate has a concave curvature, which improves the pressure bearing capacity of the water tank. There are no 45 degree or 90 degree flanges near the plate, making it more flexible and adaptable during assembly.
