SMC Fire Water Tank

The development history of SMC combination water tank:
Developed countries internationally rarely use steel plates and concrete water tanks
In 1962, Germany introduced SMC combined water tanks and established JS standards in 1980. Since 1986, over 90% of high-rise buildings have adopted SMC combined water tanks;
The United States adopted SMC combination water tanks in the 1970s and established the American National Standard in 1984.
Some countries in Western Europe, Southeast Asia, the Middle East, Africa, and other regions also widely use SMC water tanks. Beijing, Shanghai, Nanjing, Hainan and other places in China have also vigorously advocated the application of some SMC water tanks, and the initial use effect is good. In the future, it is the trend for industrial and civil buildings to adopt SMC water tanks. SMC combination water tank is one of the popular new types of water tanks internationally!

Several standards for SMC fiberglass water tank testing:
1、 Cracks or delamination: primarily refers to the separation between fabric layers and the cracking of the fabric tape. The characteristic impression of the film is that cracks or delamination in the laminated board are mostly straight and have sharp or "zigzag" shaped black lines at both ends; The cracks or delamination in the wrapped products are mostly straight or slightly wavy black lines, or shuttle shaped impressions with a wide center and pointed ends; The shape of cracks in molded products varies depending on the shape of the product, often presenting as sharp, curved black lines at both ends.

2、 Resin aggregation: refers to the situation where a certain part of the product contains too much resin, resulting in film impressions that are similar to cracks or delamination. However, the contrast between the impressions of cracks with a relatively equal degree is small, and the impression summary is not clear.
3、 Loose: refers to a decrease in the fineness of a certain part of the product, with irregularly scattered small pores or small cracks, and small resin aggregates present. The impression feature of the film is irregular layered cloud like black stripes.

4、 Wrinkles: They can be divided into circumferential wrinkles (scattered along the circumference of the product) and axial wrinkles (along the axial direction of the product) according to their different directions. The impression characteristics of the film are wavy.
5、 Metal doping: The impression feature of metal doping in fiberglass in the film is a white impression with the same shape as the doped metal. The square SMC water tank can only be used after all inspection items are qualified.
