Fiberglass Water Tank
Characteristics and scope of use of fiberglass water tanks:
The fiberglass water tank is assembled from high-quality SMC water tank panels as a whole. Its characteristic is the use of food grade resin, so the water quality is good, Clean and pollution-free, the product has the characteristics of high strength, corrosion resistance, beautiful appearance, long service life, and convenient maintenance and management. 1. Fiberglass water tanks are used in ordinary residential buildings, commercial and residential buildings, office buildings, residential communities, and machinery Close the water supply for daily life and firefighting in schools, hotels, etc; 2. Various types of circulating water Cooling water and hot water supply system water。
Structural characteristics of fiberglass composite water tank:
The structural design of the fiberglass composite water tank is mainly determined by calculating the structural strength and stiffness to determine the structural dimensions. The design requirements are external
Beautiful appearance, easy construction, and easy overall assembly and disassembly. The plate structure is reinforced with a spherical surface, which is combined with steel plate water tanks and concrete Compared to traditional water tanks, earthen water tanks have their own characteristics and creativity. Although the initial investment of modular water tanks is larger than traditional water tanks, they have The advantages of small self weight, easy installation, and easy maintenance and cleaning will undoubtedly be welcomed by a large number of users.
Installation method of fiberglass water tank:
Fiberglass water tanks have the advantages of no leakage, no deformation, no pollution, and long service life. They are easy to assemble and have a beautiful appearance. They can be assembled into water tanks of different tonnages according to user needs. 1. During installation, leave a maintenance passage of not less than 800mm between the box and the wall, and the top and bottom of the box should not be less than 500mm; 2. During civil construction, first prepare the concrete strip foundation; 3. After assembly, the outlet and drain pipes should be closed, and the inlet pipe should be opened. If there is no leakage within 24 hours after filling with water, it is considered qualified; 4. Provide construction power and inspect sealing water at the construction site.
Guidelines for selecting fiberglass water tanks:
1. The water tank adopts a combination of standard plates, which are available in three types: 1000 × 1000, 1000 × 500, and 500 × 500. 2. The length, width, and height dimensions of the water tank are selected based on 500.
3. Construction technical requirements for water tank foundation: a. The overall foundation plane composed of concrete
braces shall have a horizontal tolerance of no more than 5mm, and the difference in diagonal length of the plane shall not exceed 20mm. b. The horizontal distance from the foundation end face to the wall (four sides) shall not be less than 300mm. Some countries in Western Europe, Southeast Asia, the Middle East, Africa, and other regions also widely use SMC water tanks. In recent years, Beijing, Shanghai, Nanjing, Hainan and other places in China have also vigorously advocated the use of some SMC water tanks, and the initial use effect is good. In the future, it is the trend for industrial and civil buildings to adopt SMC water tanks.
